How can I include the room dimensions in the documentation?

Tag
Published

You would have to apply a workaround to maintain the dimensions of the building/room in the documentation. Like in the video, you can use the dimensioning tool to create the building/room dimensions. You can then save a view and add it to the documentation.

Step-by-Step:

  1. Open a room or similar that you want to measure in the 2D view
  2. Go to the ‚Construction‘ mode and choose the tool >Help lines and labelling< in the left sidebar
  3. Select the >Draw new dimension line< action in the menu on the right side
  4. The first two clicks in the CAD view define the start and end point of the dimension line
  5. Please note: Before you end the action with the third click, you have to determine the desired position of the dimension line by moving the mouse
  6. Then click on a free area in the CAD view or press the Esc key on your your keyboard in order to make the dimension labelling visible.
    Tip: In order to format e.g. the text size you have to click the corresponding dimension line in the CAD view and then use the functions in the menu on the left side
  7. After you have measured everything, switch to the >Views< tool
  8. Select the desired 2D view in your CAD window and click on >Save new view<
    Tip: Use the full size of the viewer. You can also give the image a name in the menu on the left, which will then be listed in the documentation
  9. Switch to the >Documentation< mode
  10. Choose the tool >Selected outputs< and then select e.g. the page >Views<
  11. After you have done this, go to the >Configure page< option. It can be found below the modes
  12. Under >Existing graphics<, select your saved view with the dimension lines
    You can also change the scale of this 2D view in the menu
  13. Select >Add< and exit the menu using the >Back to page view< option or the F2 key
  14. Then your view with the room dimensions appears on the desired page
